The 51.2V LiFePO4 server rack battery is a compact yet powerful energy storage solution designed for modern telecom, data center, and industrial applications. Its lithium iron phosphate chemistry ensures safe operation, minimal voltage drop, and consistent energy delivery under fluctuating loads. This rack-mounted battery is engineered for flexible installation, allowing integration into both standard cabinets and custom power setups. With intelligent monitoring and thermal management, it protects against overcharge, over-discharge, and temperature extremes, extending service life. Ideal for high-demand, off-grid, or backup power scenarios, this battery combines reliability, efficiency, and scalability to meet evolving energy needs.
| Project | Main Parameter |
|---|---|
| Rated Voltage | 51.2V (40–57.6V) |
| Rated Capacity | 200Ah |
| Continuous Charging Current | 50A |
| Continuous Discharge Current | 150A |
| Size | 580 × 442 × 222 mm ±1mm |
| Weight | 80 kg ±1kg |
| Optional Features | Power Display, GPS, Circuit Breaker |
| Purpose | Base Station Backup Power |
If you want to discover the full potential of our 51.2V LiFePO4 server rack battery, see how it can enhance the reliability and efficiency of your power systems, or explore a customized solution tailored to your specific requirements, please contact our team for detailed guidance and expert support.
Selecting a reliable and high-performance energy storage solution is critical for ensuring uninterrupted operations in telecom, data centers, and industrial applications. Our 51.2V LiFePO4 server rack battery offers an optimal balance of energy density, safety, and longevity, making it an ideal choice for mission-critical backup power systems. Unlike conventional lead-acid or standard lithium batteries, our LiFePO4 technology provides stable voltage output, superior thermal management, and minimal capacity loss over thousands of cycles.
Safety and reliability are at the core of our design. Each battery incorporates an advanced Battery Management System (BMS) that continuously monitors voltage, current, and temperature, safeguarding against overcharge, over-discharge, short circuits, and thermal extremes. Intelligent cell balancing ensures uniform energy usage, prolonging the life of the battery while maintaining consistent performance. The rugged design and flame-retardant casing protect the battery from physical damage, making it suitable for both indoor rack installations and controlled outdoor environments.
Flexibility is another key advantage. The 51.2V LiFePO4 server rack battery is compatible with standard 19-inch rack systems and can be connected in parallel for larger capacity setups. This modular approach allows businesses to scale their energy storage in line with growing power requirements, ensuring that operations remain uninterrupted even during peak demand. The compact and lightweight form factor also simplifies installation, reducing labor and setup costs.
In addition to superior technology, we provide comprehensive support from consultation to deployment. Our team of experts works closely with clients to assess power requirements, recommend optimal configurations, and provide guidance on installation and maintenance. This combination of advanced technology, practical design, and dedicated service ensures that our batteries deliver not only power but also peace of mind.
By choosing our 51.2V LiFePO4 server rack battery, you are investing in a solution that guarantees reliable, efficient, and scalable backup power. Our commitment to quality, innovation, and customer satisfaction ensures that your critical systems remain operational, safe, and optimized for long-term performance, even under challenging conditions.
The 51.2V LiFePO4 server rack battery is a high-capacity energy storage solution designed for telecom towers, data centers, industrial backup systems, and critical infrastructure. Engineered for long-term reliability, it provides stable power supply and uninterrupted performance, even in challenging environments where conventional batteries may fail. Its modular design allows for scalable deployment in standard 19-inch racks, making it suitable for both compact installations and large-scale energy storage networks.
This battery is built with premium lithium iron phosphate (LiFePO4) cells, known for their thermal stability, long cycle life, and inherent safety. The housing uses impact-resistant, flame-retardant materials to protect internal components from environmental stress. High-quality copper busbars and industrial-grade connectors ensure efficient energy transfer and minimal heat generation, supporting both safety and durability.
Each unit undergoes precise assembly with automated equipment and extensive quality testing. An integrated Battery Management System (BMS) continuously monitors voltage, current, and temperature, providing protection against overcharge, over-discharge, short circuits, and thermal extremes. Advanced cell balancing ensures uniform energy distribution, maximizing efficiency and extending service life over thousands of charge cycles.
The 51.2V LiFePO4 server rack battery is ideal for telecom base stations, server rooms, remote microgrids, industrial control systems, and other mission-critical applications. Its scalable design allows multiple units to be connected in parallel for increased capacity. It is also suitable for temporary deployments such as construction sites, mobile emergency units, and remote research stations.
The battery meets international safety and quality standards, including UL, CE, and RoHS certifications. It is designed to comply with telecom and industrial specifications, providing reliable operation under temperature fluctuations, vibration, and mechanical stress.
Q1: What is the nominal voltage and capacity?
A: 51.2V nominal voltage and up to 200Ah capacity (~10.24 kWh usable energy).
Q2: How long is the battery lifespan?
A: Typically 3,000–6,000 cycles depending on depth of discharge.
Q3: Can multiple batteries be connected together?
A: Yes, units support parallel connection for higher total energy storage.
Q4: Is it suitable for outdoor installation?
A: Yes, it is designed to operate reliably under a wide range of temperatures and environmental conditions.
Q5: Does it support remote monitoring?
A: Yes, the BMS supports CAN, RS485, and optional Modbus interfaces.
Capable of handling sudden power demands instantly, ensuring connected equipment continues operating without interruption.
Optimized internal layout reduces physical space usage, making it ideal for tight rack environments and compact server rooms.
Uses non-toxic LiFePO4 chemistry with lower environmental impact compared to traditional lead-acid alternatives.
Integrated monitoring can provide early warnings for potential performance issues, enabling proactive system management.
Operates reliably across wide temperature ranges, supporting both hot industrial sites and colder outdoor deployments.
Supports quick parallel expansion for systems that require incremental energy growth without replacing existing units.
The 51.2V LiFePO4 server rack battery is ideal for unconventional or mobile energy setups, such as temporary data centers, pop-up telecom sites, portable research labs, and off-grid field operations. It supports short-term high-demand power, emergency deployments, and rapidly changing environments where traditional stationary power solutions are impractical.
Provides portable, reliable energy for short-term data centers deployed in events, disaster recovery, or experimental IT setups.
Supports rapid deployment of temporary telecommunications equipment where grid power is unavailable or unreliable.
Delivers consistent power to mobile labs conducting field tests, environmental studies, or engineering experiments in remote areas.
Ideal for powering equipment in construction sites, emergency response zones, or remote work camps without access to conventional electricity.
Supplies energy for temporary high-load applications, ensuring continuous operation of critical devices during peak usage periods.
