Balcony Solar Power System with Storage is designed to provide a practical renewable energy solution for urban residents living in apartments or compact housing. It integrates solar panels, an inverter, and a battery unit to capture sunlight and store electricity efficiently for later use. This system allows users to generate clean energy directly from balcony spaces, reducing dependence on the traditional power grid and lowering electricity costs. Its compact and modular design makes installation simple and adaptable to different building types. Balcony Solar Power System with Storage is ideal for sustainable living in cities where space and rooftop access are limited
| Model NO. | BM2400 |
|---|---|
| Nominal Output Power | 0.8kW |
| Nominal Output Current | 3.48A |
| Max. Output Power | 2.4kW |
| Max. Output Current | 10.43A |
| Nominal Output Voltage | 230V |
| Nominal Grid Frequency | 50Hz±5% |
| AC Input Charging | AC230V 2400W Max |
| Solar Input Charging | No PV |
| Inverter Efficiency | ≥90% |
| MPPT Efficiency | No PV |
| Battery Conversion Efficiency | ≥85% |
| Nominal Output Power | 2.4kW |
| Peak Output Current (1 second) | 10.43A |
| Nominal Output Voltage | 230V |
| Nominal Grid Frequency | 50Hz±2% |
| Total Voltage Harmonic Distortion | THDv < 3% |
| Interruption Time of Backup Switch | ≤10MS |
| Main Unit Capacity | No Battery |
| Battery Module Model | B2400 |
| Battery Module Capacity | 2400Wh |
| Number of Modules per Main Unit | 1~5PCS |
| Nominal Voltage of Battery Module | DC48V |
| Protection | Overvoltage/Undervoltage/Overcurrent/Overload/Short-Circuit/Overheating Protection; Insulation Monitoring; Residual Current Monitoring; Anti-islanding Protection; Type II DC/AC Surge Protection |
| Open Ecosystem Integration Support | Smart Meter, Smart Plug, Infrared Meter, Heat-pump Power Controller |
| Safety Protection Feature | Tibber Pulse infrared meter, Tibber dynamic electricity price direct acquisition, EverHome smart meter, HomeWizard P1 Meter |
| General Data | same as BM1600 PRO |
If you would like to explore the full capabilities of our balcony solar power system with storage, understand how it improves energy efficiency in compact urban environments, or discuss a customized solution tailored to your apartment or project needs, please feel free to contact our team for detailed information and professional support.
The balcony solar power system with storage is designed for users who prioritize reliable backup power and high output capability in residential environments, making it particularly suitable for households that require stable energy supply during outages or unstable grid conditions. Unlike low-power balcony systems, this solution provides up to 2.4kW output power, allowing it to support multiple essential appliances simultaneously.
The system integrates a hybrid inverter capable of delivering 0.8kW nominal output and up to 2.4kW maximum output, ensuring sufficient power capacity for critical household loads such as refrigerators, communication systems, lighting, and small appliances. The DC48V battery architecture enhances system efficiency and reduces energy loss during power conversion, while maintaining stable voltage output.
The system is equipped with comprehensive protection mechanisms including overvoltage, overcurrent, short-circuit, overheating protection, and anti-islanding functionality, as well as Type II AC/DC surge protection, ensuring safe and reliable operation under various electrical conditions.
Through integration with smart meters and energy management platforms, users can monitor energy usage in real time, manage backup priorities, and optimize system performance based on household needs and electricity pricing conditions.
This system is ideal for users who require strong backup capability, including families in areas with unstable grid supply, home office users, and households with critical electronic devices.
The balcony solar power system with storage is a compact yet powerful energy storage solution designed to provide reliable backup power and efficient energy management in residential settings.
The system consists of a hybrid inverter delivering up to 2.4kW output power, combined with modular lithium battery storage units rated at 2400Wh each, allowing users to scale energy capacity up to five modules depending on backup duration requirements.
The system features fast backup switching within 10 milliseconds, ensuring uninterrupted operation during grid outages, while maintaining stable 230V AC output and low harmonic distortion for safe appliance usage.
Designed for balcony installation, the system features a compact structure, efficient thermal management through natural cooling, and low standby power consumption, making it suitable for continuous residential operation.
Designed for railing and wall mounting, it fits naturally into compact balcony environments without structural modifications.
Allows direct consumption of locally generated electricity, reducing reliance on external supply sources.
Maintains consistent electrical delivery for daily appliances under varying environmental conditions.
Enables users to adjust energy usage patterns based on generation and consumption timing.
Uses low-noise design principles suitable for residential living areas and shared buildings.
Supports low-carbon lifestyle adoption by enabling localized renewable energy use in dense city environments.
The balcony solar power system with storage is applied in compact urban living environments where traditional rooftop solar installation is not feasible. It is commonly used in high-density apartment buildings, rental housing units, and small residential spaces to enable localized electricity generation and utilization. The system is also suitable for home offices, studio apartments, and light commercial settings requiring supplementary power support. By integrating energy production and storage within limited balcony space, it provides a practical solution for users seeking greater energy autonomy, improved power efficiency, and reduced dependence on conventional grid supply in modern cities.
Ideal for urban apartment residents, the system enables clean energy generation directly from balconies without requiring rooftop access, helping reduce monthly electricity costs.
Designed specifically for limited spaces, it fits easily on balcony railings or walls, making it a practical solution for dense city environments.
Suitable for small shops, offices, and studios, it provides stable supplementary power to reduce reliance on the grid and improve energy efficiency.
In the event of power outages, the system ensures continuous electricity for essential loads, improving reliability and operational continuity.
Widely used in eco-friendly housing and green building initiatives, it supports carbon reduction goals and promotes decentralized renewable energy adoption.
