Solar Balcony Storage System is designed to bring efficient renewable energy generation into compact urban living environments. By combining photovoltaic panels with an integrated battery unit, it allows users to capture solar energy during the day and store it for later use. This setup improves energy utilization, reduces reliance on grid electricity, and helps lower utility costs. Its space-saving design makes it suitable for balconies, small terraces, and limited installation areas. Solar Balcony Storage System offers a practical approach for modern households seeking flexible, clean, and decentralized energy solutions without the need for complex infrastructure or large rooftop systems
| Model NO. | BM2400 |
|---|---|
| Nominal Output Power | 0.8kW |
| Nominal Output Current | 3.48A |
| Max. Output Power | 2.4kW |
| Max. Output Current | 10.43A |
| Nominal Output Voltage | 230V |
| Nominal Grid Frequency | 50Hz±5% |
| AC Input Charging | AC230V 2400W Max |
| Solar Input Charging | No PV |
| Inverter Efficiency | ≥90% |
| MPPT Efficiency | No PV |
| Battery Conversion Efficiency | ≥85% |
| Nominal Output Power | 2.4kW |
| Peak Output Current (1 second) | 10.43A |
| Nominal Output Voltage | 230V |
| Nominal Grid Frequency | 50Hz±2% |
| Total Voltage Harmonic Distortion | THDv < 3% |
| Interruption Time of Backup Switch | ≤10MS |
| Main Unit Capacity | No Battery |
| Battery Module Model | B2400 |
| Battery Module Capacity | 2400Wh |
| Number of Modules per Main Unit | 1~5PCS |
| Nominal Voltage of Battery Module | DC48V |
| Protection | Overvoltage/Undervoltage/Overcurrent/Overload/Short-Circuit/Overheating Protection; Insulation Monitoring; Residual Current Monitoring; Anti-islanding Protection; Type II DC/AC Surge Protection |
| Open Ecosystem Integration Support | Smart Meter, Smart Plug, Infrared Meter, Heat-pump Power Controller |
| Safety Protection Feature | Tibber Pulse infrared meter, Tibber dynamic electricity price direct acquisition, EverHome smart meter, HomeWizard P1 Meter |
| General Data | same as BM1600 PRO |
If you would like to explore the full capabilities of our Solar Balcony Storage System, understand how it improves energy efficiency in compact urban environments, or discuss a customized solution tailored to your apartment or project needs, please feel free to contact our team for detailed information and professional support.
The solar balcony storage system is uniquely positioned for users who want the benefits of energy storage and cost optimization but do not have access to solar panels, making it ideal for apartments where PV installation is restricted or not feasible. Unlike traditional solar systems that rely heavily on photovoltaic input, this solution focuses on energy storage, smart charging, and consumption optimization, allowing users to benefit from energy management without solar infrastructure.
The system supports AC input charging up to 2400W, enabling rapid battery charging during low electricity price periods, which is particularly advantageous in regions with time-of-use pricing models. The lithium battery modules, each rated at 2400Wh and based on DC48V architecture, ensure efficient energy storage and stable discharge performance, while maintaining battery conversion efficiency above 85 percent.
With a maximum output power of 2.4kW, the system is capable of supporting multiple household appliances simultaneously, including refrigerators, communication devices, and lighting systems, while maintaining stable voltage output at 230V with minimal harmonic distortion, ensuring safe operation for both standard and sensitive electronics.
The system integrates with advanced smart energy platforms, enabling users to monitor electricity usage, track energy costs, and automate charging schedules based on dynamic pricing signals, which significantly improves energy efficiency and cost control over time.
This system is ideal for users without solar panels, renters, cost-conscious households, and anyone seeking a simple yet powerful energy storage solution for daily use and backup.
The solar balcony storage system is a dedicated energy storage solution designed for residential users who want to optimize electricity usage and ensure backup power availability without relying on photovoltaic generation.
The system features a hybrid inverter platform delivering 0.8kW nominal output and up to 2.4kW peak output, combined with modular lithium battery storage units rated at 2400Wh each, allowing expansion up to five modules for increased capacity. The DC48V battery system ensures stable voltage regulation and efficient energy transfer throughout the system.
The system relies on AC grid charging with a maximum input power of 2400W, allowing users to store electricity during off-peak periods and discharge it during peak demand hours, effectively reducing electricity costs and improving energy usage efficiency.
With a fast switching time of less than 10 milliseconds, the system ensures continuous power supply during outages, while maintaining stable output performance and low harmonic distortion for safe appliance operation.
1. What is a Solar Balcony Storage System used for?
It is used to generate and store solar energy in compact urban spaces, allowing users to power home appliances and reduce electricity costs.
2. Can it be installed in an apartment balcony?
Yes, it is specifically designed for balcony or small-space installation without requiring rooftop access or major structural changes.
3. Does the system work during power outages?
Yes, stored energy in the battery can provide backup power when the grid is unavailable.
4. How much maintenance does it require?
It requires very low maintenance, mainly occasional inspection and basic cleaning of solar panels.
5. Is the system expandable for higher energy demand?
Yes, many models support modular expansion, allowing users to increase storage capacity as needed.
Designed specifically for balcony environments, it fits compact residential layouts without requiring structural modifications.
Enables direct use of stored solar power when needed, improving daily electricity management efficiency.
Operates with low noise output, making it suitable for residential settings and shared living spaces.
Supports a variety of applications from apartments to small offices, adapting to different energy needs.
Automatically balances energy distribution between usage and storage for optimized system performance.
Promotes reduced grid dependence and supports low-carbon living in densely populated city environments.
The Solar Balcony Storage System is applied in modern urban environments where space and installation constraints limit traditional energy solutions. It is commonly used in high-rise apartments, compact residential units, and rental properties to enable localized power generation and storage. The system also fits small-scale commercial settings such as studios and home offices, where stable supplemental electricity is required. In addition, it supports sustainable building initiatives by integrating renewable energy directly into living spaces, helping users reduce dependency on the public grid while improving overall energy autonomy and efficiency in densely populated areas.
Ideal for urban apartment residents, the system enables clean energy generation directly from balconies without requiring rooftop access, helping reduce monthly electricity costs.
Designed specifically for limited spaces, it fits easily on balcony railings or walls, making it a practical solution for dense city environments.
Suitable for small shops, offices, and studios, it provides stable supplementary power to reduce reliance on the grid and improve energy efficiency.
In the event of power outages, the system ensures continuous electricity for essential loads, improving reliability and operational continuity.
Widely used in eco-friendly housing and green building initiatives, it supports carbon reduction goals and promotes decentralized renewable energy adoption.
